High Speed Retail 2d Desktop Barcode Scanner Cmos Type

Name: High Speed Retail 2d Desktop Barcode Scanner Cmos Type
Brand: DYscan
Price: 1 USD

Buy cheap High Speed Retail 2d Desktop Barcode Scanner Cmos Type product

Brand Name : DYscan

Model Number : DP8580M

Certification : CE ROHS FCC IEC

Place of Origin : China

MOQ : 2pcs

Price : negotiable

Payment Terms : T/T, Western Union,PAYPAL

Supply Ability : 100000pcs/month

Delivery Time : 5-7days

Packaging Details : 54*34*34CM/30pcs /Carton

Scan Type : CMOS

Resolution : ≥5mil/0.127mm(PCS90%,Code 39)

Decoding speed : 640*480

Depth of field : 0-380mm

Scan Mode : Continuous ,Auto sense

Print Contrast Signal : ≥25%

Symbologies : 1D 2D

Dimension : L86.7mm * W96.7mm * H143.6mm

Interface type : USB, RS232

Weight : 270g（without cable)

Contact Now

2D Desktop Scanner

DP8580M is a 1.0 mega pixel high performance 2D desktop scanner with advanced CMOS image recognition technology.

It can easily read paper, goods, screens and other media 1D 2D barcodes.

Widely used in large supermarkets, restaurant, chain stores, and grocery stores.

Feature

☆ Wide window design, auto sense scanning.

☆ 2d image technology, read paper, plastic, screen 1D 2D barcodes, etc. easily.

Performance

Scan Type	CMOS
Light Source	light: red LED,wavelength 525nm
CPU	32-bit
Resolution	1280*800 (1.0 million Global exposure)
Start time	4s
Resolution	≥4mil/0.1mm(PCS90%,CODE 39)
Decoding speed	120CM/S
Depth of field	0mm~600mm
Scan Mode	Continuous
Indicator	buzzer
Scan angle	Roll360°, Pitch±45°, Skew±32°
Print Contrast Signal	≥20%
Ambient Light	Dark environment, indoor natural light
Symbologies	1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, GS1-128, Code 39,Code 32, Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5(Straight 2 of 5),Codabar(NW-7),MSI,GS1 Databar(Omnidirectional, Limited, Expanded), etc. 2D: QR Code, Micro QR Code, Data Matrix,PDF417, Micro PDF 417, Aztec,etc.

Physical Parameter

Weight	≈540g(without cable)
Dimension	L84.0 mm * H151.5 mm * W151.5mm
Communication Mode	USB(USB-KBW,USB-COM),RS232
Interface Type	10PIN crystal head
Power Supply	DC 5V@280mA(work)

Environmental

Operating temperature	-20℃ to 55℃
Storage temperature	-20℃ to 60℃
Humidity	5% to 95%(non-condensing)
Drop Height	1.2m
Transport Vibration Test	10H@125RPM

Detail Image

High Speed Retail 2d Desktop Barcode Scanner Cmos Type
